Tellhow EST, in cooperation with CSSC, can provide the users with a global leading level of dual fuel power generation set. The engine is arranged in line with output power of 405kw per cylinder. We can provide customers with four power generating sets of 6, 7, 8 and 9. In the process of R & D, the engine has been cooperating with AVL in depth and has adopted a lot of advanced technology. The main advantages include:
Model |
ES 2000 DF5 |
ES 2340 DF5 |
ES 2670 DF5 |
ES 3000 DF5 |
Engine Model |
6ACD320DF |
7ACD320DF |
8ACD320DF |
9ACD320DF |
Electric power (kW) |
2000 |
2695 |
3080 |
3000 |
Bore (mm) |
320 |
320 |
320 |
320 |
Stroke(mm) |
420 |
420 |
420 |
420 |
Configuration |
I6 |
I7 |
I8 |
I9 |
Rated Speed (RPM) |
750 |
750 |
750 |
750 |
Electrical Efficiency (%) (Gas model) |
46.5% |
46.5% |
46.5% |
46.5% |
Electrical Efficiency (%) (Diesel model) |
46% |
46% |
46% |
46% |
Genset Length(mm) |
8137 |
8955 |
9710 |
10450 |
Genset Width (mm) |
2437 |
2437 |
2437 |
2437 |
Genset Height (mm) |
4102 |
4102 |
4305 |
4305 |
Genset Weight (Kg) |
55000 |
62000 |
69000 |
76000 |
